RF Radio Cell Phone Jamming Wifi Blocker Jammer 433MHz With Remote Control
Description
1. The TSL-B7 is a Wifi Signal cell phone jammer with 7 high-gain omni-directional antennas.
2. It can be used to jam Wifi, GPS, CDMA, GSM, 3G & 4G LTE, UHF, VHF, etc.
3. The design of metal case helps the jammer to work for long time with excellent heat-dissipation effect.
4. All you need to do is to attach the plug and antennas, then press the switch.
5. The jammer will block all target signals around automatically and there is nothing else for you.
6. This model can reach 4 to 16 channels for option, interference of all mobile phone signal, WIFI 2.4G signal, Wireless Camera & GPS L2, VHF, UHF, etc. Within the effective range for up to 50meters, Practical for some locations of special purpose such as, hospitals, gas stations and so on.
7. Specially designed for easy and simple use, this device does not require complicated installation or any professional knowledge.
Specifications
| Output port | Frequency | Output power | Jamming range |
| CDMA800 | 869-894MHz | 3 Watts | 5-25 meters |
| GSM900 | 925-960MHz | 3 Watts | 5-25 meters |
| GSM1800 | 1805-1880MHz | 3 Watts | 5-25 meters |
| WCDMA | 2110-2170MHz | 3 Watts | 5-25 meters |
| WiFi 2.4G | 2400-2485MHz | 2 Watts | 5-50 meters |
| 4G LTE 2600 | 2620-2690MHz | 3 Watts | 5-25 meters |
| GPS L1 | 1975MHz | 1 Watts | 5-50 meters |
| Optional | The frequency of each channel can be customized by different requirement.
The jammer can be monitored and controled by monitoring system for centralized management.
It can also be powered by the car adapter |
| Warranty | One year from delivery date |
| Power supply | 50 to 60Hz, 100 to 240V AC, With AC adapter |
| Packing list | Mainframe*1, Antenna*7, Power supply*1 |
| Applications | Meeting Room, Cars, Rest Room, Hospital, Theaters, Church, Office Room, Prison, etc. |
Customized Isolating Signal Bandwidth
| CDMA | 851-894MHz |
| GSM | 925-960MHz |
| DCS | 1805-1880MHz |
| PCS | 1930-1990MHz |
| 3G | 2110-2185MHz |
| 4G (LTE) | 725-785MHZ |
| 4G (Wimax) | 2300-2410MHZ |
| Lojack | 167-175MHZ |
| RF Radio | 315MHz |
| RF Radio | 433MHz |
| GPSL1/Glonass | 1575.42MHz |
| VHF | 135-175MHz |
| UHF | 435-475MHz |
| GPSL2/Glonass | 1227.42MHz |
| Wireless Camera 1.2G | 1100-1200MHz |
| Wireless Camera 2.4G | 2400-2483MHz |
| Wi-Fi/Bluetooth | 2.4G |
| WI-FI, 5G | 5500-5900MHz |
Wecome to do OEM/ODM, we can do customized frequency based above frequencies.
Jamming monitoring system are availble for all our jammers for projects which require all the jammers be monitored and controlled together by computer from internet.
Application Area
1.it can be applied at prisons, meeting rooms, conference rooms, museums, galleries, theaters, concert halls, churches, temples, restaurants, classrooms, training centers, factories, banks, trains, bus and more.
2.For some locations of special purpose such as hospitals, gas stations and more, Please do field test first to make sure no interference happened to the normal operation of their equipment and instrument.
Whip antenna specification
| Electrical Specifications |
| Frequency Range | The same as the jammer channel |
| Impedance | 50 Ohm |
| VSWR | <1.5 |
| Gain | 3dBi |
| Polarization | Vertical |
| Radiation Direction | Omni |
| Max. Power Input-watts | 50 W |
| Mechanical Specifications |
| Length | 210mm |
| Radiating Material | Whip |
| Connector | SMA |
| Radome colour | Black |
Notice
The power shall not be switched on before connected all the antennas. Don’t take off antennas when the mainframe is in the working condition.
